Single Piece Ball Valve

Get a Price/Quote

Single Piece Ball Valve Specification

Pressure
Up to 40 Bar

Structure
Single Piece

Connection
Screwed (BSP/NPT), Flanged

Channels
2 Way

Caliber
Full Bore

Material
Stainless Steel

Power
Manual

Media
Water, Oil, Gas, Steam

Port Size
15mm to 100mm

Flange
ANSI, DIN, JIS Standard

Finish
Mirror/Polished

Application
Industrial, Chemical, Petrochemical, Water Treatment

End Connection
Threaded / Flanged

Operation
Quarter Turn

Leakage
Bubble Tight Shutoff

Body Material
CF8 / CF8M / WCB

Seat Material
PTFE

Handle Material
Stainless Steel with Insulation Sleeve

Testing Standard
API 598

Design Standard
BS 5351 / API 608

About Single Piece Ball Valve

Single Piece Ball Valve

Leveraging on our client centric approach, we manufacture, supply and export Single Piece Ball Valve. Highly skilled professionals at our company use high quality components for manufacturing these valves. Our range of ball valves comes in different sizes. High precision, excellent durability and excellent surface finish are the features due to which our ball valve is highly demanded by our clients. Extreme cautions are kept in mind by our professionals while manufacturing the entire stock of Single Piece Ball Valve in order to match the international quality parameters.

TECHNICAL SPECIFICATIONS:

Size	Inch	1/2	3/4	1	1 1/4	1 1/2	2	2 1/2	3	4
Size	DN	15	20	25	32	40	50	65	80	100
L		64	70	84	96	107.5	122	142	158	178
A		21.7	27.1	33.8	43.2	48.6	61.1	73.5	90.5	116.1
NB		12.5	19	25	32	38	50	63	75	100
H		41	49	58	72	77	86	102	112	145

Material of construction:

Body & End Piece	ASTM A 216 GR. WCB/ A 351 GR. 8/8M/CF 3/3M
Ball	A 351 GR. CF 8/8M/CF 3/3M
Stem	AISI 304/316/304L/316L
Seat & seal	PTFE/GFT/CFT
Stud & Nut	C.S./B7/2H/SS 304/316

Superior Engineering for Critical Applications

Built to the highest international standards (BS 5351 / API 608), our single piece ball valves offer reliability in demanding environments. With full bore design for unrestricted flow and bubble-tight shutoff, they are ideal for controlling water, oil, gas, and steam media up to 40 bar pressure.

Versatile Connections and Sizes

Available in port sizes ranging from 15mm to 100mm, our ball valves come with both threaded (BSP/NPT) and flanged connections to suit any system requirement. Meeting ANSI, DIN, and JIS flange standards enables seamless integration, regardless of your projects regional specifications.

FAQs of Single Piece Ball Valve:

Q: How does the single piece ball valves quarter-turn operation function?

A: The quarter-turn operation allows users to quickly open or close the valve with just a 90-degree rotation of the handle, providing fast and reliable isolation for flow media such as water, oil, gas, or steam.

Q: What benefits does the PTFE seat provide in these ball valves?

A: PTFE seats offer excellent chemical resistance and a low friction surface, ensuring leak-proof performance and longevity even in corrosive or high-temperature environments.

Q: When should I select a single piece ball valve for my application?

A: Single piece ball valves are ideal when you need a cost-effective, reliable shutoff for low to medium pressure applications, particularly where compact size and ease of maintenance are priorities.

Q: Where can these single piece ball valves be installed?

A: They can be installed in a wide range of industrial systems, including piping setups for water treatment, chemical processes, petrochemical plants, and various other industrial and utility applications.

Q: What is the process for ensuring bubble-tight shutoff in these valves?

A: Each valve is meticulously manufactured using precision machining and then tested according to API 598 standards, guaranteeing a bubble-tight shutoff for safe and reliable operation.

Q: How does the insulated stainless steel handle improve valve usage?

A: The insulation sleeve on the stainless steel handle provides a secure, burn-protected grip, enhancing operator safety around high-temperature or cryogenic media.
